Euroboor ECO.36+ 36mm Low Profile Drill 110v

€1,059.00 (Inc. VAT)

€860.98 (Ex. VAT)

Low profile magnetic drilling machine

Ø 12 - 36 mm / 10.3 kg

The Euroboor ECO.36+ magnetic core drilling machine is the lowest drilling machine in the market, measuring only 165 mm (6 1/2″) height. This magnetic core drilling machine is perfect for drilling in spaces with limited heights such as H-beams, steel structures, plates, profiles, etc. The portable ECO.36+ is equipped with innovative electronics which offer more safety, significantly reduce the risk of damage of the machine, tool and workpiece and protects the user in case of excessive vibrations or sudden displacement. The lifespan is considerably longer and you avoid high maintenance costs.

This machine features:

Integrated motor cable

Gyro-Tec

Power surge protection

Power fluctuation protection

Carbon brush wear indicator

Automatic shut-off

Additional features

One-speed gearbox

User friendly Quick-Connect cutter fitment system

Carrying handle and safety strap attachment

Left and right mount ability of detachable ratchet feed handle

Integrated tool cooling and lubrication

Removable and slideable safety guard

Lubrication bottle with magnet attachment

Strong dual coil CNC machined 2-way magnet, causing the machine to use less energy, generate less heat and therefore lasts longer

Reduced risk of damaging machine, tools and workpiece and hurting operator

Suitable for use in areas and workplaces where power supply is of less quality

Reduced risk of armature damage

Reduced risk of control unit(s) damage

Timely service notification to avoid additional cost by unexpected downtime or unnecessary part replacement

Technical data

MetricImperial

Annular cutting	Ø 12 - 36 mm
Twist drilling	Ø 1 - 14 mm
Countersinking	Ø 10 - 40 mm
In-corner drilling	0˚ - 50 mm (center to edge) 90˚ - 53 mm (center to edge) 45˚ - 60 mm (center to edge)
Length	310 mm
Width	135 mm
Height	165 mm
Stroke	40 mm
Weight	10.3 kg*
Magnet (l x w x h)	80 x 160 x 37 mm
Magnetic force	1,200 kg
Motor power	1,050 W
Total power	1,100 W
Speed (no load)	700 rpm
Speed (load 1,050 W)	400 rpm
Spindle (Weldon)	19.05 mm
Voltage	220 - 240 V / 50 - 60 Hz
*Exclusive power cord and handle
