Overview
GCM 18V-216 DC Professional reaches a large cutting capacity of 70x300 mm and the power of a corded 1,600 W mitre saw thanks to its BITURBO Brushless technology. It offers a two-point dust extraction for a cleaner and healthier working environment and, even when its integrated side extensions are increasing workpiece control, it remains compact and easy to transport. Versatile usage in different materials due to speed selection and ECO mode for extended runtime via the user interface. Further customisation by using the Toolboxx app.
The GCM 18V-216 DC is perfect for cross, mitre, and bevel cuts in timber beams and wooden composites as well as floor panels, aluminium, and plastic. It is compatible with the Click & Clean System, all Bosch GTA mitre saw stands, and all Professional 18 V batteries and chargers (Bosch Professional 18V System). For maximum power, use ProCORE18V ≥ 5.5 Ah.
It also features a LED light and a dual bevel function.
Specifications
Cutting capacity, 0° |
70 x 300 mm |
Cutting capacity, 45° mitre |
65 x 214 mm |
Cutting capacity, 45° bevel |
45 x 306 mm |
Mitre setting |
52 ° L / 60 ° R |
Bevel setting |
47 ° L / 47 ° R |
Tool dimensions (width x length x height) |
817 x 569 x 825 mm |
No-load speed* |
2,500 – 4,500 rpm |
Saw blade diameter |
216 mm |
Saw blade bore diameter |
30 mm |
Weight* |
15.3 kg |
Battery voltage |
18.0 V |
Packaging dimensions (width x length x height) |
588 x 772 x 445 mm |
Inclusive
- 1 x circular saw blade, Expert for Wood, 216 x 30 x 1.7 mm, (2608644519)
- 1 x Bluetooth Low Energy module GCY 42 Professional (1600A016NH)
- SDS saw blade lock (spare part number 1 609 B05 323)
- Clamp (1609B04224)
- Stop plate (1609B02365)
- Screw (1609B00263)
- Wrench Socket (1609B06988)
- Cardboard box
